SUBZERO Thermostat Singe Probe Controller SZ-7510T

  • Memory Retention and Compressor Protection: The controller includes memory retention and time delay features to safeguard compressors.
  • Cooling and Heating Output: It provides both cooling and heating outputs, ensuring comprehensive temperature control.
  • Spade Terminals: Equipped with spade terminals designed for easy and secure connection to compressors.
  • Auto Operation in Sensor Error: In the event of a sensor error, the controller can initiate auto operation, maintaining temperature control.
  • Power Switch: The unit features a power switch for convenient operation and control.
Categories: HVAC Products
Brand: SUB-ZERO
SKU: SZ-7510T
icon 65.00
All Prices are VAT Inclusive
As low as icon 17.50/month or 4 interest-free payments
Add to Cart
OR
Pay with link
bulk For Bulk Orders You May Click The Link To Reach Us
Click Here
ADD TO WISHLIST SHARE

ABOUT THE PRODUCT

SUBZERO Thermostat Singe Probe Controller SZ-7510T

Subzero Sz-7510t Touch Sensitive Temperature Controller

The Subzero SZ7510 Temperature Controller is designed for heating applications, specifically when the P1 parameter is set to ‘1,’ except for the SZ-7520/25/29-P models. It is also commonly referred to as a Defrost Controller. The SZ-7529-P variant, in particular, serves as a defrost controller and features an integrated power relay capable of directly driving compressor loads of up to 20 Amperes.

This versatile Subzero Temperature Controller offers a user-friendly interface with an alphanumeric parameter display, allowing precise configuration for various applications. With a wide measuring range spanning from -50°C to 99°C, it accommodates a diverse range of temperature control needs.

SpecificationDetails
ManufacturerSub-Zero
Select Model                                                                    SZ-7510-C(1 Relay with RS-485), SZ-7510-P(1 Relay with Powerswitch in Keypad), SZ-7510-T(1 Relay with Powerswitch in touch), SZ-7510-WV(1 Relay WallMount)
Measuring ParametersTemperature
Temperature Range-50°C to +99°C
Accuracy+/- 1°C
Resolution+/- 1°C
Display2 X 14.2 mm (0.56″) LED
Operating Temperature5°C to 50°C (non-condensing)
Storage Temperature-20°C to 70°C (non-condensing)
Power Input230Vac +/-10%, 50-60Hz (Other on request)
InputNTC Probe, SZ-N75
Output1 SPDT relay 8 (3)A, 250Vac, 1 SPST relay 20A, 250Vac (For SZ-7569/29-P only)
Front CoverPolycarbonate plastic
Data StorageNon-volatile EEPROM memory
Panel Cutout29 X 71 mm
Probe Tolerance at 25°C+/- 0.3°C
MountingFlush panel mounting with fasteners
HousingBlack, ABS Plastic
BuzzerSZ-B75. 10Vdc, 10mA (Only for SZ-7515/25-P)
ConnectionScrew terminal blocks. ≤ 2.5sqmm one wire/terminal only
Protection ClassIP 65
DimensionsFront: 75 X 34.5 MM, Depth: 71 MM (w/o back lid)
