METALCLAD Speedalloy Mechanical Repairs

THE LEAK STOPPER – AND MORE!
The First Choice for Fast, Reliable Mechanical Repairs.

METALCLAD SpeedAlloy is a quick curing, 100% solids, polymeric ‘leak stopper’ used for making fast, effective repairs to equipment that must be returned to service almost immediately.

METALCLAD SpeedAlloy has a paste consistency when first mixed then transforms into a metal-hard composite in just minutes.

Quick Curing
Trowelable
Requires No Heat
Unlimited Shelf Life
100% Solids
Safe & Simple To Use

Use on…
Pipes & Tanks
Sumps
Radiators & Fuel tanks
Cracked & holed casings
Damaged keyways
Stripped threads
Scored shafts
Hydraulic rams
Technical Data
Volume capacity per 167gm “A Pack”
4.3 in3 / 72 cc
Mixed density
0.085 lbs per in3 / 2.33 gm per cc
Coverage rate per “A Pack” @ 0.25 in / 6mm
17.2 in2 / 0.012 m2
Shelf life
Indefinite
Volume Solids
100%
Mixing ratio Base Activator
By Volume 1 1
By Weight 2 1
Working Life and Cure Times
Ambient Temperature Working Life Machining Light Load Full Mechanical Chemical Immersion
41°F 5°C 10 min. 60 min. 2 hrs. 72 hrs.
59°F 15°C 7 min. 45 min. 1 hrs. 48 hrs.
77°F 25°C 5 min. 30 min. 40 min. 36 hrs.
86°F 30°C 3 min. 20 min. 30 min. 24 hrs.
Physical Properties

Typical Values Test Method
Compressive strength 22,500 psi 1575 kg/cm2 ASTM D-695
Flexural strength 8,500 psi 595 kg/cm2 ASTM D-790
Izod impact strength 1.3 ft lbs/in 0.69 j/cm ASTM D-256
Hardness – Rockwell R-90
ASTM D-785
Hardness – Shore D 84
ASTM D-2240
Tensile Shear Adhesion

Steel 2300 psi 161 kg/cm2 ASTM D-1002
Aluminum 2100 psi 147 kg/cm2 ASTM D-1002
Copper 2250 psi 158 kg/cm2 ASTM D-1002
Stainless Steel 1800 psi 126 kg/cm2 ASTM D-1002
Surface resistivity 1 x 1015 ohms ASTM D-257
Volume resistivity 1 x 1015 ohm/cm ASTM D-257
Dielectric constant 7.5 ASTM D-150
Chemical Resistance
Acetic acid (0-10%) EX Methyl alcohol G
Acetic acid (10-20%) G Methyl ethyl ketone G
Acetone G Nitric acid (0-10%) EX
Aviation fuel EX Nitric acid (10-20%) G
Butyl alcohol EX Phosphoric acid (0-5%) EX
Calcium chloride EX Phosphoric acid (5-10%) G
Crude oil EX Potassium chloride EX
Diesel fuel EX Propyl alcohol EX
Ethyl alcohol G Sodium chloride EX
Gasoline EX Sodium hydroxide EX
Heptane EX Sulfuric acid (0-10%) EX
Hydrochloric acid (0-10%) EX Sulfuric acid (10-20%) G
Hydrochloric acid (10-20%) G Toluene G
Kerosene EX Xylene EX

EX – Suitable for most applications including immersion
G – Suitable for intermittent contact, splashes, etc.
